Self-Closing Retrofit Polyester Braid Wrap Sleeve
Woven from monofilament and multifilament polyester yarns, it provides a lightweight, cost-effective and tough solution for the protection of a wide range of components. It does not trap heat or moisture.
This wraparound's self-wrapping, low profile and flexible design fits tightly to wire harnesses making it an ideal bundling solution in restricted areas without affecting the flexibility of the components it protects. Its inherent flexibility allows it to conform to irregular shapes and contours.
What's special about semi-rigid braided sleeving?
1.Operating temperature: -40ºC - 150°C
2.Flammability: UL94 V0
3.Fluid and chemical resistant
4..Keeps it's flexibility under a wide range of temperatures
5.Easy installation
6.Resists gasoline, chemicals & cleaning Solvents
7.25% overlap designed to keep wires fully covered
8.Cut & Abrasion Resistant
certifications
Specification
Part No |
Size ID |
Overlap | Standard Color |
Standard Packing (L) |
MJ-STHW003 | 3mm | 25% |
Black White Orange |
200m/spool |
MJ-STHW005 | 5mm | 100m/spool | ||
MJ-STHW008 |
8mm |
100m/spool | ||
MJ-STHW010 | 10mm | 100m/spool | ||
MJ-STHW013 | 13mm | 50m/spool | ||
MJ-STHW016 | 16mm | 25m/spool | ||
MJ-STHW019 | 19mm | 25m/spool | ||
MJ-STHW025 | 25mm |
25m/spool |
||
MJ-STHW029 | 29mm |
25m/spool |
||
MJ-STHW032 | 32mm |
25m/spool |
||
MJ-STHW038 | 38mm |
25m/spool |
||
MJ-STHW050 | 50mm |
25m/spool |
Application
Cable Management
Automotive harnesses
Hoses and tubing
A/C line
Hydraulic and fuel lines
Control Cables
